3100-6GT-I

VOLKTEK|Network Security Appliances-Industrial Firewall-3100-6GT-I
VOLKTEK|Network Security Appliances-Industrial Firewall-3100-6GT-I_right back_1200x1200
VOLKTEK|Network Security Appliances-Industrial Firewall-3100-6GT-I_top_1200x1200
Product Highlights
  • 6 x 10/100/1000 RJ45 ports
  • 2 x RS-232 COM ports
  • 1 x VGA port
  • 2 x USB 3.0
  • 1 set (LAN 1&2) Bypass Port (Pair)
  • Operating temperatures -40℃~75℃ (-40°F~167°F)
  • USB
  • -40°C-75°C
  • Auto MDI/MDIX
  • Console port
  • Fanless
  • IP Code 30
  • QoS
  • VPN
  • Wall Mount
  • Firewall
  • ROHS CE FC
Overview

The 3100-6GT-I protective equipment is Volktek's industrial control firewall specially designed for industrial control systems (ICS) and data acquisition and supervisory control systems (SCADA). It is suitable for automated factories, manufacturing plants, oil & gas, energy units (telecommunications, water plants), power plants), etc., can prevent different network environments from being attacked.

The 3100-6GT-I is specially designed for extreme temperatures, humidity, dust, and vibration environments. It has a built-in hardware bypass function to prevent the equipment power supply or system itself from malfunctioning. Network traffic originally processed by the 3100-6GT-I It can still be transmitted, allowing enterprises to extend IT security to the OT environment.

Volktek 3100-6GT-I integrates new deep packet inspection and filtering functions for network communication protocols commonly used in industrial control systems, such as Modbus, DNP3, IEC-61850, and Citrix, and enhances the capabilities of the SCADA environment where ICS systems are located. Detailed control and supervision can detect connection packets, and traffic, and isolate dangerous attacks.

Features
  • Physical and Virtual Isolation of Automation Network
  • Monitor Automation and Execute Virus and Vulnerabilities
  • Infection Control and Isolation
  • Supported Industrial Protocols
  • OPC Intrusion Prevention
  • Authentication & Access Management
  • Application Allowlisting
  • VPN
  • Dashboard
  • Disaster Recovery
  • Support USB
  • Central Management (CMS and Cloud)
Specifications

Standards

Firewall Throughput

1.8 Gbps

VPN Throughput

200 Mbps (IPsec AES)

OPC Throughput

480 Mbps

Anti-Virus Throughput

350 Mbps

Max. Sessions

200,000

Interface

10/100/1000Base-T

6

Serial Console Port (RS232)

2

USB Port

2

Bypass Port (Pair)

1 (LAN 3&4)

LED Sign

PWR, SATA DOM, System, ByPass, LINK/ACT, 1000, 100

SATA DOM

64G SATA DOM (SLC)

Network Interface

Speed: Giga

Fixed Port: 1

Custom Port: 5

Power

DC

9~36VDC

Mechanical and Environment

Housing

Metal (IP30 Protection)

Operating Temperature

-40ºC ~ 75ºC (-40ºF ~ 167ºF)

Storage Temperature

-40ºC ~ 85ºC (-40ºF ~ 185ºF)

Operating Humidity

10%~80% (non-condensing)

Storage Humidity

10%~80% (non-condensing)

Weight

1,310 g (2.89 lb)

Mount Options

DIN Rail / Wall Mount

Dimension (WxHxD)

74.5 x 146 x 126 mm (2.93 x 5.75 x 4.96 in)



Ordering Information

Model Description
3100-6GT-I Managed 6 x 10/100/1000 RJ45 with LAN Bypass Industrial Firewall



*Specifications subject to change without prior notice.

Download
File Name Release Date Download
3100-6GT-I Datasheet 2026-04-24
