Atthis 6500-24GS4XS
Product Highlights
  • 20 x FX/GbE SFP, 4 x FE/GbE Combo RJ45/SFP ports, 4 x multi-rate GbE/10G SFP+ uplink ports for ring topology and redundancy
  • The multi-rate ports allow to reduce CapEx offering two available speeds 1Gb and 10G
  • 1 x Console Port for command-line interface and USB port supports firmware upgrades, saves configuration files and downloads log files
  • Quick troubleshooting to identify the interface errors through cable test and DDMI functions
  • Operating temperatures 0°C~60°C (32°F~140°F)
  • USB
  • 0°C-60°C
  • 10G
  • ACDC power redundancy
  • Code Redundancy
  • Device Locking
  • Power Backup
  • QoS
  • SNMP
Overview

Atthis 6500-24GS4XS-C is a 20-port, multi-rate FX/GbE SFP downlink, 4-port FE/GbE Combo RJ45/SFP, and 4-port, GbE/10G SFP+ uplink designed for high network bandwidth demands of internet users that work from home and to support workable video calls, play video games and movie-streaming.

It covers long fiber stable connectivity to help in the digitalization of rural areas and solves the difficulties of internet service providers related to maintenance, safety, and recovery. The device offers a consistent user platform, is theft-proofed, and reduces management costs. The RJ45 type console port allows outbound network troubleshooting when networks go wrong. The USB port, designed to save configuration files, save system log files, and upgrade firmware, reduces network downtime and operational costs. The analog and digital inputs help to monitor and alert about the device’s performance.

The switch uses hardware protective features that monitor the ports and their performance to protect its lifetime. This hardened grade switch has a temperature operation between 0°C~60°C (32°F~140°F) is designed for rack-mount and cabinets in indoor applications without air conditioning.

Features

10G Uplink Interface
4 slots SFP+ for 1G/10G fiber uplinks can deliver wire-speed throughput with low latency for data-intensive application. 10G networking is less expensive than highly specialized Fiber Channel (SAN) and do not needs a specialized skill set for installation and management. To compare with aggregating multiple Gigabit Ethernet links, it can help reducing the cost and increasing manageability efficiently.


Multicast Video Service Support
Equipped with Device Lock feature to lock the device to a specific network making it impossible to be reconfigured to work on a different network if it is stolen.


Redundant Ring for Fast Network Recovery
Even a few seconds of missed communications due to link failures can cause inconvenience, and recovery can become critical. Volktek's proprietary Xpress Ring in Atthis-6500 Series rapidly reacts to such link failures and recovers in less than 50ms, a much faster fail-over time to support nonstop transmissions. This is critical for networks handling heavy video and data traffic. In addition, ERPS, Dual Homing, LACP and RSTP/MSTP provide a highly reliable network with redundancy connections whenever required and guarantee continuous network uptime.


Efficient Traffic Prioritization
Network applications need different levels of services delivered to them reliably without any transmission delays and interruptions. The Atthis-6500 Series has comprehensive QoS mechanisms that assign priority to applications and send only specific dedicated traffic to them. In addition, bandwidth management functions of the switch allocate greater bandwidth for mission-critical communications. With increased control, administrators can prevent unpredictable errors and utilize the bandwidth more effectively.


Enhanced Control and Security
The Atthis-6500 Series implements several defense mechanisms such as ACL, DHCP snooping, ARP, IEEE 802.1X and Port Security to deliver robust network security and enables service providers to offer more stable services on a more secure network.


Efficient Network Monitoring and Management
It is designed with SNMP (Simple Network Management Protocol) v1/v2c/v3 and RMON (Remote Monitoring) for real-time traffic analysis, flexible network management and monitoring options which increased efficiency and performance. Whether managing from an 'in-band' SNMP management station or Internet web browser, or 'outof-band' on console port, the 6500 series makes network monitoring and troubleshooting easy. SNMP is used for collecting information from, and configuring, network devices on an Internet Protocol (IP) network. Volktek Managed switch provides SNMP agent that works with third-party SNMP management software to monitor the device status.

Specifications

Standards

IEEE 802.3

10BASE-T

IEEE 802.3u

100BASE-TX

IEEE 802.3ab

1000BASE-T

IEEE 802.3u

100BASE-FX

IEEE 802.3z

1000BASE-SX/LX

IEEE 802.3ae

10GBASE-SR/LR/ER

IEEE 802.3

Nway Auto-negotiation

IEEE 802.3x

Flow Control

IEEE 802.3ad

Link Aggregation

IEEE 802.1AB

LLDP

IEEE 802.1ad

QinQ

IEEE 802.1D

STP

IEEE 802.1w

RSTP

IEEE 802.1s

MSTP

IEEE 802.1p

Class of service, priority protocols

IEEE 802.1Q

VLAN tagging

IEEE 802.1X

Port Authentication

IEEE 1588v2

PTP

Interface

Ports

20 x 100/1000 SFP Slots

4 x 100/1000 Combo Ports

4 x 1G/10G SFP+ Slots

1 x RJ45 Console Port

1 x USB 2.0 Port

LED Panel

PWR1, PWR2, ALM, POST, 100/1000, 10G, LNK/ACT

Digital Input

2 x pairs, Dry Contact

Digital Output

Alarm Relay output

24VDC, 1A

Power

Input Voltage

AC: 100~240V, 50~60Hz

DC: 48V

Power Consumption

6500-24GS4XS-A-C: 30W

6500-24GS4XS-AB-C: 50W

Mechanical and Environment

Housing

Metal Case

Mounting

Rack Mount

Operating Temperature

0ºC~60ºC (32ºF~140ºF)

Storage Temperature

-20°C~70°C (-4°F~158°F)

Operating Humidity

5 to 95% RH (non-condensing)

Storage Humidity

5 to 95% RH (non-condensing)

Cooling Fan

2

Dimension (WxHxD)

440x44x284.7mm (17.3x1.73x11.21 inch)

Weight

3890 g (8.77 lbs)



Ordering Information

Model Description
6500-24GS4XS-A-C Managed 20 x FX/GbE SFP & 4 x FE/GbE Combo RJ45/SFP & 4 x 1G/10G SFP+ Switch, with AC Power Input
6500-24GS4XS-AB-C Managed 20 x FX/GbE SFP & 4 x FE/GbE Combo RJ45/SFP & 4 x 1G/10G SFP+ Switch, with AC Power Input,
Battery Charge Function Included
6500-24GS4XS-D-C Managed 20 x FX/GbE SFP & 4 x FE/GbE Combo RJ45/SFP & 4 x 1G/10G SFP+ Switch, with DC Power Input



*Specifications subject to change without prior notice.
