INS-8005E
Product Highlights
  • 5 x 10/100 RJ45 ports for Fast Ethernet speed application devices with Premium features
  • Auto-negotiation ports allow operation without extra device installation
  • Keeps flow at a constant rate to avoid overflow and prevents data storms with Flow and Storm Control
  • Prevents packet loss with VLAN Passthru by forwarding VLAN packets without dropping or modifying them
  • Industrial QoS (EIP (EtherNet/IP), PROFINET, and GOOSE packets), per-port priority, 802.1p Tag
  • Operating temperatures-40℃~75℃ (-40°F~167°F) and IP30 metal housing
  • -40°C-75°C
  • Auto Negotiation
  • DIN Rail
  • ESD Protection
  • IP Code30
  • Surge Protection
  • Wall Mount
  • ROHS CE FC
Overview

INS-8005E is an unmanaged 5-port, 10/100 RJ45 downlink industrial switch with Premium features for very elementary interconnection between devices, but high traffic requirements. It offers auto-negotiation on all its ports to aggregate devices easily in Industrial Ethernet applications. The device can be used with multi-axis robots and their peripherals such as PLCs, HMIs, and legacy devices. Additionally, it offers auto-negotiation on all its ports to aggregate devices easily in industrial ethernet applications. Prioritizes data with industrial QoS priority for Ethernet/IP, PROFINET, and GOOSE packets.

The switch offers various in-built traffic optimization and network performance features to prioritize important industrial data packets, prevent the loss of data during communication, and stable transmission; like flow control and VLAN Passthru. It prioritizes industrial protocols for industrial applications, like Ethernet/IP, PROFINET, and GOOSE packets. Additionally, it offers per-port and 802.1p Tag Quality of Service to ensure the delivery of high-priority data.

This switch is built with industrial grade components, enclosed in an IP30 metal case to protect the device from tools and hazards. Designed to withstand vibration, shock, free fall, interference, and temperatures ranging from -40℃~75℃ (-40°F~167°F) it suits extreme industrial environments.

Features


It's Accident Proof
Engineered to withstand electromagnetic interference, electrostatic discharge, power surge, over-voltage, over-current in the event of an accident.



Redundant Power System
To guarantee power runs continuously the switch is designed to be simultaneously connected to two power supplies and an alarm through a standard industrial terminal block. If one power supply stops working the switch will start feeding its power on the alternative power supply and the alarm will go off to notify technicians about the event.



Simple Installation and Compact Size
Auto MDI/MDI-X (medium dependent interface / MDI crossover) on all ports for simple connection to other switches and hubs.



Comprehensive QoS
Supports IEEE 802.1p Quality of Service (QoS) which enhances bandwidth utilization to ensure time-sensitive data gets delivered efficiently to mission-critical applications without any delay even during a burst of high traffic.




Specifications

Standards

IEEE 802.3

10BASE-T

IEEE 802.3u

100BASE-TX

IEEE 802.3

Nway Auto-Negotiation

IEEE 802.3x

Flow Control

IEEE 802.1p

Class of Service

Interface

Ports

5 x 10/100Base-TX (RJ45)

LED Panel

PWR, 100, LNK/ACT

Power

Input Voltage

12~48VDC

Connection

Terminal Block

Power Input Polarity Protection

Present

Current Overload Protection

Present

Power Consumption

3W

Mechanical and Environment

Housing

Aluminum (IP30 Protection)

Mounting

DIN-Rail, Wall Mount

Operating Temperature

-40°C~75°C (-40°F~167°F)

Storage Temperature

-40°C~85°C (-40°F~185°F)

Operating Humidity

5 to 95% RH (non-condensing)

Storage Humidity

5 to 95% RH (non-condensing)

Weight

160 g (0.3 lb)

Dimension (WxHxD)

23.6 x 111.5 x 73.8 mm (0.93 x 4.39 x 2.90 in)



Ordering Information

Model Description
INS-8005E Unmanaged 5 x 10/100 RJ45 Industrial Switch



*Specifications subject to change without prior notice.

Download
File Name Release Date Download
INS-8005E Datasheet 2022-11-01
INS-8005E Photo 2021-11-01
